Special vans & commercial vehicle rear-view color camera • CVC-CVUL

Rear-view camera for vans and commercial vehicles

– Night vision with 9 Infrared LEDs
– IR range: 8 to 10 m
– TV system: PAL
– Max consumption : 120mA
– Power supply: 12V/DC
– Operating temperature : -40°C~70°C
– Max humidity : 95% max
– Storage temperature: -40°C~80°C
– Max humidity : 95%
– Lens : f=2,2 mm, F=2.5
– Viewing angle: 120°
– IP69
– Pixels : 728 x 488 pixels
– Sensing area : 4,6228 mm x 3,61 1 2 mm
– Resolution : 500 TV lines
– Horizontal sync. frequency: 15.625KHz
– Vertical sync. frequency: 50Hz
– Minimum requ. light: 0.1 Lux (jour), 0 Lux (avec IR)
– Microphone : no
– Video output: 1.0Vp-p, 75 Ohm
– Signal/noise ratio : > 48 dB
– Balance of white: automatic
